L Series

High Productivity PET Blow Molding Machine

Preform Infeed System
1.The entire series is fixated on the machine to reduce machine configuration space.
2.The preform infeed system has multiple levels of protection system to ensure precise preform infeed and zero deficient products.
3.Uses continuous preform infeed system.
Transfer System
1.Effectively reduces heating distance, energy consumption, and increases heating efficiency.
2.Horizontal level configuration; preform does not have to be turned; simple structure
Heating System
1.When replacing the lamps, the heating oven can be turned over on the machine for maintenance.
2.The water pipe directly runs through the heating oven to protect the valve.
3.Optimized ventilation system allows cooling of preform surface.
4.Preform temperature monitoring functions
Transfer and Variable Pitch System
1.Servo-driven preform transfer system with grippers secured on the timing belt.
2.Servo-driven variable pitch system for fast and accurate preform handling between two components
Blowing and Clamping System
Servo-driven clamping system with CAM synchronized base mold operation
Pressure / Blowing System
Uses a combination of high-speed and precision blowing valves to achieve high productivity
Control System
1.Touch-panel interface for easy operation.
2.10.4 inch LCD touch screen with 64K color
Miscellaneous
1.Connected structure in fully electric version ensures high speed operation and precise positioning
2.Uses fast mold replacement structure
3.Low energy consumption, low wear and tear, and low pollution

  • CPSB-LSS16

    Fully Electric

    Max.capacity:0.6 ltr

    Neck Lnt-diameter:MAX, 30/25mm

    Spindle chain pitch:38

    Cavity:16

    Output BPH:24000 (0.6L)


  • CPSB-LS12

    Fully Electric

    Max.capacity:2 ltr

    Neck Lnt-diameter:MAX, 38mm

    Spindle chain pitch:50

    Cavity:12

    Output BPH:18000 (0.6L)


  • CPSB-LS9

    Fully Electric

    Max.capacity:1.5 ltr

    Neck Lnt-diameter:MAX, 30/25mm

    Spindle chain pitch:38

    Cavity:9

    Output BPH:13500 (0.6L)


  • CPSB-LSS12H

    Fully Electric

    Max.capacity:0.6 ltr

    Neck Lnt-diameter:MAX, 30/25mm

    Spindle chain pitch:38

    Cavity:12

    Output BPH:11200 (0.6L)


  • CPSB-LS8

    Fully Electric

    Max.capacity:2 ltr

    Neck Lnt-diameter:MAX, 38mm

    Spindle chain pitch:50

    Cavity:8

    Output BPH:12000 (0.6L)


  • CPSB-LSS8

    Fully Electric

    Max.capacity:0.6 ltr

    Neck Lnt-diameter:MAX, 30/25mm

    Spindle chain pitch:38

    Cavity:8

    Output BPH:13600 (0.6L)


  • CPSB-LS6H

    Fully Electric

    Max.capacity:1 ltr

    Neck Lnt-diameter:MAX, 38mm

    Spindle chain pitch:50

    Cavity:6

    Output BPH:6000 (0.6L)


  • CPSB-LS6H

    Fully Electric

    Max.capacity:1 ltr

    Neck Lnt-diameter:MAX, 38mm

    Spindle chain pitch:50

    Cavity:6

    Output BPH:6000 (0.6L)


  • CPSB-LSS12

    Fully Electric

    Max.capacity:0.6 ltr

    Neck Lnt-diameter:MAX, 30/25mm

    Spindle chain pitch:38

    Cavity:12

    Output BPH:18000 (0.6L)


  • CPSB-LL4

    Fully Electric

    Max.capacity:6 ltr

    Neck Lnt-diameter:MAX, 55 mm

    Spindle chain pitch:76

    Cavity:4

    Output BPH:4600 (6L)


  • CPSB-LS2G

    Fully Electric

    Max.capacity:4-12 ltr

    Neck Lnt-diameter:MAX, 72mm

    Spindle chain pitch:90

    Cavity:2

    Output BPH:1200 (12L)


  • CPSB-L1G

    Fully Electric

    Max.capacity:12-20 ltr

    Neck Lnt-diameter:MAX, 72mm

    Spindle chain pitch:90

    Cavity:1

    Output BPH:600 (12L)
