Phoenix Series

PET Stretch Blow Molding Machine

Pneumatic Version
1. Automatic preform infeed, heating, and blowing
2. Patent chain adjustment for easy repair and maintenance.
3. Widely applied heating design that can be adapted for different products.
4. Touch-panel interface, allowing easy operation.
5. Modular design for easy repair and maintenance.
6. Cost saving for increased competitiveness.
7. Small floor footprint
Electric Version
1. Positioning servo, fast and stable
2. Molding servo for low vibration and noise
3. Blowing servo for easy adjustment
4. Heating temperature with compensation control
5. High pressure blowing for recycling and reuse
Applicable Types
Mineral Water, CSD, Seasonings, Carbonated Drinks, Tea, Fruit Juice, Distilled Water, Alcoholic Beverages, Cooking Oil, Cleaning Agents, Cosmetics

  • CPSB-TS4000E

    Fully Electric / Standard

    Max.capacity:1.5 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:4

    Output BPH:5600



  • CPSB-TSS6000E

    Fully Electric / Standard

    Max.capacity:0.6 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:6

    Output BPH:8400


  • CPSB-T3000E

    Fully Electric / Standard

    Max.capacity:3 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:3

    Output BPH:4200



  • CPSB-TS2000E

    Fully Electric / Standard

    Max.capacity:1.5 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:2

    Output BPH:2800


  • CPSB-TS4000W

    Fully Electric / Standard

    Max.capacity:1.5 ltr

    Neck Lnt-diameter:63mm

    Spindle chain pitch:-

    Cavity:4

    Output BPH:4000


  • CPSB-TS2000W

    Fully Electric / Standard

    Max.capacity:1.5 ltr

    Neck Lnt-diameter:63mm

    Spindle chain pitch:-

    Cavity:2

    Output BPH:2000


  • CPSB-TSS6000

    Fully Electric / Standard

    Max.capacity:0.6 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:6

    Output BPH:6000


  • CPSB-TS4000

    Fully Electric / Standard

    Max.capacity:1.5 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:4

    Output BPH:4000


  • CPSB-TS4000H

    Fully Electric / Standard

    Max.capacity:1.5 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:4

    Output BPH:2000


  • CPSB-T3000

    Fully Electric / Standard

    Max.capacity:3 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:3

    Output BPH:3000


  • CPSB-TSS3000

    Fully Electric / Standard

    Max.capacity:0.6 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:3

    Output BPH:3000


  • CPSB-TS2000

    Fully Electric / Standard

    Max.capacity:1.5 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:2

    Output BPH:2000


  • CPSB-TS2000H

    Fully Electric / Standard

    Max.capacity:1.5 ltr

    Neck Lnt-diameter:38mm

    Spindle chain pitch:-

    Cavity:2

    Output BPH:1000

Fruit Juices
Special Bottle
Mineral Water
